TOC,MAINS 3-15 CU,TAP 6-35 2B CCW35DB

Product DetailsSicame CCW35DB Tap Off Connector – Double BoltApplicationSicame have designed the CCW series of Tap Off Connectors (TOC’s) for use on Australia’s utility networks where the mains is bare copper.CCW series have been specially designed to provide a waterproof connection between insulated overhead services and bare copper mains. Electrical contractors and ASP’s can safely and easily install the CCW35DB.CCW235E specifications Mains Range  – Bare Copper 7/1.00 to 19/3.00, 5.5 to 135mm2 (3-15mm OD) Service Taps Range – Insulated PVC or XLPE Copper or Aluminium 2 x 6-35mm2 Two (2) Service Taps Bolt Head 13mm AF High visibility shear-off identification tags Box of 12Installation NotesUse only a 13mm, six-point hexagon socket to tighten bolts (ARS Code 02345).All other connections made on the service and consumer’s cable must also be waterproof to prevent moisture ingress through the cable into the connector.For more info about this product, please contact us
